GF44DC - DC FFU Fan Filter Unit 11751175350mm

GF44DC - DC FFU Fan Filter Unit 11751175350mm Specification

Usage
Industrial

Condition
New

Material
Stainless Steel / FRP

Size
Various Sizes Available

Filtration Grade
Pre Filter

Warranty
1 Year

Feature
High Quality

GF44DC - DC FFU Fan Filter Unit 11751175350mm Trade Information

Minimum Order Quantity
10 Units

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Units Per Month

Delivery Time
7 - 10 Days

Main Domestic Market
All India

About GF44DC - DC FFU Fan Filter Unit 11751175350mm

Fan Filter Unit

GF44DC-Technical Data Sheet

SN	Items		Specifications
1	Dimensions (mm)		11751175350
2	Weight (kg)		19
3	Noise (dB)		55
4	(1)Total Static Pressure (Pa)		280
5	Material	Casing	Galvanized Aluminum
6	Material	Impeller	Full Aluminum
7	(2)Operating Air Speed with filter(m/s )		0.45
8	Maximum Air Volume without filter (CMH)		2000
9	Working Air Volume with filter (CMH)	Low	300-1200 (Stepless Speed Control)
10		Medium
11		High
12	Motor	Power (W)	150
13		Max RPM	1200
14		Type	DC Brushless Motor
15		Efficiency Class	IE4
16	Control Mode		Single/Group Control
17	Start Mode		Software / Control Panel Start
18	Safe Operating Voltage		200V-240V
19	Safe Operating Temperature (C)		<65
20	Average Daily Power Consumption (kWh)		1.92

Explanation

Fan Filter Unit is a self powered, high efficiency filtration system designed for cleanroom air supply. It integrates a high performance fan module with a HEPA or ULPA filter, delivering clean and consistent airflow. By overcoming filter and system resistance, the FFU ensures reliable air quality control in critical environments. Our FFUs are known for their flexibility and adaptability ideal for zoning control and adjusting to process changes. These units are reusable and serviceable, making them cost effective over time. The design supports negative pressure supply, reducing the need for ductwork and minimizing the risk of contamination.
Available in sizes like 2x4 and 4x4 configurations, our FFUs offer air volumes ranging from 850 to 2400 CFM depending on application needs. With advanced features such as software based control panels, direct switch starts, and safe operation under high temperature environments, Rayshen FFUs are a reliable choice for any cleanroom..
